Home /Products/Single Phase Inverter/8kw 10kw Solar Hybrid Split Phase Inverter 8kw Single Phase Split Inverter Hybrid Inverter 556*345*182mm

8kw 10kw Solar Hybrid Split Phase Inverter 8kw Single Phase Split Inverter Hybrid Inverter 556*345*182mm

1 set
MOQ
8kw 10kw Solar Hybrid Split Phase Inverter 8kw Single Phase Split Inverter Hybrid Inverter 556*345*182mm
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: SEI Series
Input Voltage: 90V-280V
Output Voltage: 230V
Output Current: 100A
Output Frequency: 50/60Hz
Output Type: Single
Size: 556*345*182mm
Type: DC/AC Inverters
Inverter Efficiency: 99.5%
Certificate: IEC/EN/ FCC
Warranty: 5 Years
Weight: 20kg
Product Name: Residential Solar Hybrid Inverters
Rated Output Power: 5500W
Battery Type: Lead-acid / Li-ion / User Defined
Protection Level: IP65
Working Temperature: -25~55℃, >45℃ Derated
Basic Infomation
Certification: IEC/EN/ FCC
Model Number: SEI series
Payment & Shipping Terms
Packaging Details: Standard Carton box, one set in one box. Anti-shock packaging material, with foam, ensure transport safety
Supply Ability: 30000 Set/Sets per Month
Product Description
Products Description
Product Advantages:
1.Touch screen display 2.PV and utility power take the load at same time(can setting) 3.MAX PV Array power 6000W 4.Wide PV input range 120-450VDC 5.External Wi-Fi / GPRS device optional 6.Parallel operation up to 6 units 7.AC charging and AC output time setting 8.Connected with battery optional 9.Energy generated record,load record,history Information and fault record 10.On&Off Grid with energy storage
Specification
MODEL
RS-SEI-5K-S
CAN BE SET
INVERTER OUTPUT
Rated Output Power
5500W
Max.Peak Power
11000W
Rated Output Voltage
230Vac (single-phase L+N+PE)
Y
Load Capacity of Motors
4HP
Rated AC Frequency
50/60Hz
Y
Waveform
pure sine wave
Switch Time
10ms（typical）
Parallel capacity
/
BATTERY
Battery Type
Lead-acid / Li-ion / User Defined
Y
Rated Battery Voltage
48Vdc
Voltage Range
40-60Vdc
Y
Max.MPPT Charging Current
100A
Y
Max.Mains/Generator Charging Current
60A
Y
Max.Hybrid Charging Current
100A
Y
PV INPUT
Num. of MPP Trackers
1
Max.PV array power
6000W
Max.input current
22A
Max.Voltage of Open Circuit
500Vdc
MPPT Voltage Range
120-450Vdc
MAINS / GENERATOR INPUT
Input Voltage Range
UPS mode：170～280Vac；APL mode：90～280Vac
Y
Frequency Range
50/60Hz
Bypass Overload Current
40A
EFFICIENCY
MPPT Tracking Efficiency
99.9%
Max. Battery Inverter Efficiency
＞90%
GENERAL
Dimensions
556*345*182mm
Weight
20Kg
Protection Degree
-25~55℃,>45℃ derated
Humidity
Internal Fan
COMMUNICATION
Embedded Interfaces
RS485 / CAN / USB / Dry contact
Y
External Modules （Optional）
Wi-Fi / GPRS
Y
CERTIFICATION
Safety
IEC62109
EMC
EN61000,FCC part 15
