HOPEWIND Inverter On Grid 10kw 3phase 380v 30kw Grid Tie Inverter Solar Inverter 10 KW Grid Tie With Limiter 360*450*220mm

2 boxes
MOQ
HOPEWIND Inverter On Grid 10kw 3phase 380v 30kw Grid Tie Inverter Solar Inverter 10 KW Grid Tie With Limiter 360*450*220mm
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: HopeSun 20KTL
Input Voltage: 1100V
Output Voltage: 400V (Three Phase) (380V Optional)
Output Current: 28.9A
Output Frequency: 50Hz / 60Hz
Output Type: Triple
Size: 360*450*220mm
Type: DC/AC Inverters
Inverter Efficiency: 98.63%
Certificate: TUV/IEC
Warranty: 5 Years
Weight: ≤25kg
Inverter Type: On-grid Solar Power Inverter
MPPT Number: 2
Protection Level: IP65
Cooling System: Natural Cooling
Topology Structure: Transformerless
Operating Temperature Range: -40℃ ~ +60℃
Operating Altitude: 5000m (Derating Above 4000m)
Display: LED Indicator + APP
Communication: WiFi / GPRS / Anti-reversed Flow Or Self-consumption Interface
Optional: WIFI&GPRS Module / Anti-PID Module / Anti-Reversed Module
Basic Infomation
Certification: TUV/IEC
Model Number: HopeSun 20KTL
Payment & Shipping Terms
Packaging Details: 1pcs with accessories per box
Supply Ability: 200000 Set/Sets per Month
Product Description
Looking For Distributor/Agents And Providing The Best Supports And Helps To Get Win-Win
Product Description
High Power
Max DC voltage 1100v, max power 22kw
High Efficiency
Max efficiency 98.61%
High Reliability
Double channels MPPT

Lightning protection

Provide full range of lightning protection , reliable under/over voltage protection

Compact Structure

Easy for installation and maintenance

Friendly to environment

Provide clear and green energy ,Photovoltaic power generation, save electricity cost
Specification
Model
hopeSun
10KTL
hopeSun
12KTL
hopeSun
15KTL
hopeSun
17KTL
hopeSun
20KTL
hopeSun
22KTL
DC Input
Max. DC Voltage
1100V
Starting Voltage
180V
MPPT Voltage Range
200V~1000V
MPPT Range Full Load
370V-880V
450V-880V
425V-880V
Max.Current/MPPT
20A
26A/20A
30A
Number of DC Inputs
2
3
4
MPPT Number
2
AC Output
Rated Output Power
10kw
12kw
15kw
17kw
20kw
22kw
Max. Active Power(cosθ=1)
11kw
13.2kw
16.5kw
18.7kw
22kw
24.2kw
Rated Output Voltage
400V (Three Phase)(380V optional)
Operating Voltage Range
300V-480V
Rated Output Current
14.5A
17.4A
21.7A
24.6A
28.9A
31.8A
Max. Output Current
16.0A
19.1A
23.9A
27.0A
31.8A
35.0A
Rated Grid Frequency
50Hz/60Hz
Power Factor
0.8(Leading)~0.8(Lagging)
THD
＜3%
System Parameters
Max. Efficiency
98.60%
98.61%
98.62%
98.63%
98.65%
European Efficiency
98.30%
AC/DC SPD
Support
RCD
Support
PV String Fault Detection
Support
Output Overcurrent Protection
Support
Protection Level
IP65
Operating Temperature Range
-40℃ ~ 60℃
Cooling System
Natural Cooling
Standby Power Consumption
＜1W
Topology Structure
Transformerless
Operating Altitude
5000m (Derating above 4000m)
Display
LED Indicator + APP
Communication
RS 485 /WiFi / GPRS
Certification
IEC62109 / IEC61000 / IEC62116 / IEC61727 / EN50549 / CQC / CGC
Mechanical Parameters
Dimensions(W*H*D)
360*450*220mm
Weight
≤25kg
More Details Please Send Inquiry To Us
